Sale!

RUBEX HR4 (4¾in. Gearcase)

Name: RUBEX HR4 (4¾in. Gearcase)
SKU: 32050
Price: 475.00 USD
Availability: InStock

Original price was: $550.99.Current price is: $475.00.

SOLAS RUBEX HR4

Fits Yamaha 150~350HP / Evinrude/Johnson 150~300HP / Mercury 150~300HP

Price Includes Hub Kit

Rubex Hub Kit Chart

RUBEX HUB KIT APPLICATION CHART
Mercury/Mariner/Mercruiser	Hub Kit #	Hub #	Prop Category
25 HP Bigfoot 1999-2005,30 HP (2 & 4-Stroke) 1994-2005, 30 HP (Sea Pro/Marathon) 1994 & Newer, 35 HP 1984-89,40 & 50 & 70 HP (Includes Models 402, 500, & 700) 1977-1984, 45 HP 1986-1989,40-50 HP (2 & 4-Stroke, Not Bigfoot) 1977 & Newer,48 HP (Mariner) All Years,55 HP (Sea Pro/Marathon) 1995 & Newer,60 HP (Not Bigfoot or Sea Pro) 1978 & Newer, 60 HP (Not Bigfoot or Sea Pro) 1978 & Newer, 60 HP (Mariner) 1976, 65 HP 1972-1976, 70 HP 1983, 80 HP (Mariner) 1977, Model 402-500 (40 HP & 50 HP) 1974-76, Model 650 (65 HP) 1972-76, Model 700 (70 HP) 1977-84, 13 Tooth spline 3-1/4" Gearcase	RBX-114	17013300	C
40-60 HP Bigfoot, 40-140 HP (except 135 HP) V4 Gearcase 1978 & Newer; 15 tooth spline 4-1/4" Gearcase	RBX-102	17015300	D
90HP, 115HP (Command Thrust) 2014 & Newer, 135 HP 1987 & Newer, 150-300 HP 1978 & Newer; 15 tooth spline 4-3/4" Gearcase	RBX-102	17015300	E
Mercruiser Alpha One & Bravo One (less than 400HP); 15 tooth spline	RBX-102	17015300	E
Same application as RBX-102 & 300+HP (Rubber & Bronze Hub)	RBX-102B	17015301	E
For use with HD (Heavy Duty) 1.25” propshaft; 19 tooth spline (Rubber & SS Hub)	RBX-123	17016300	E+
225 EFI (4-Stroke) manufactured by Yamaha; 15 tooth spline 4-3/4" Gearcase	RBX-124	17015300	E
Evinrude/Johnson/BRP
40 & 50 HP (4-Stroke) 1999-05; 13 tooth spline 3-1/4" Gearcase	RBX-115	17013300	C
40-75 HP (Small Gearcase) 1975-2005; 13 tooth spline 3-3/8" Gearcase	RBX-111	17023300	C
40-75 HP (Large Gearcase) 1968 & Newer, 85-140 HP 1969 & Newer; 13 tooth spline 4-1/4" Gearcase	RBX-106	17024300	D
60 & 70 HP (4-Stroke) 1998 & Newer; 13 tooth spline 4-1/4" Gearcase	RBX-110	17024300	D
90 & 115 HP (4-Stroke) 2002-07; 15 tooth spline 4-1/4" Gearcase	RBX-125	17015300	D
140 HP (4-Stroke) 2002-07; 15 tooth spline 4-1/4" Gearcase	RBX-126	17015300	D
90-300 HP 1991 & Newer; 15 tooth spline 4-3/4" Gearcase	RBX-100	17025300	E
90-300 HP 1976-90; 15 tooth spline 4-3/4" Gearcase	RBX-101	17025300	E
200 & 225 HP (4-Stroke) 2004-2005; 15 tooth spline 4-3/4" Gearcase	RBX-104	17015300	E
200-300 HP G2 Engine 2014 & Newer; 15 tooth spline 4-3/4" Gearcase	RBX-151	17025301	E
Suzuki
DT 35C 1987-89, DT 40 1983-98, DF 40 & DF 50 (4-Stroke) 1999-10, DF 40A & DF 50A (4-Stroke) 2011 & Newer, DT 50 & 50M 1983-84, DT 55 1985-97, DT 60 1983-84, DF 60A (4-Stroke) 2010 & Newer, DT 65 1985-97; 13 tooth spline 3-1/4" Gearcase	RBX-115	17013300	C
DF 60 (4-Stroke) 1998-09, DF 70 (4-Stroke) 1998-08, DT 75-140 HP 1979-01; 13 tooth spline 4-1/4" Gearcase	RBX-110	17024300	D
DF 70A & DF 80A & DF 90A (4-Stroke) 2009 & Newer; 15 tooth spline 4-1/4" Gearcase	RBX-150	17015300	D
DF 90 2001-08, DF 100 2009 & Newer, DF 115 2001-12, (All 4-Stroke); 15 tooth spline 4-1/4" Gearcase	RBX-125	17015300	D
DF 115A & 140A 2013 & Newer, DF 140 2002-12, (All 4-Stroke); 15 tooth spline 4-1/4" Gearcase	RBX-126	17015300	D
DT 150-225 HP (2-Stroke) 1986 & Newer , DF 150-300 HP (4-Stroke); 15 tooth spline 4-3/4" Gearcase	RBX-104	17015300	E
Volvo
SX Sterndrives 1994 & Newer; 19 tooth spline 4-3/4" Gearcase	RBX-105	17075300	E
Yamaha
T25 HP 2010 & Newer, F30 (4-Stroke) 2001-05, F40 (4-Stroke) 1999 & Newer, F50 (4-Stroke) 1995 & Newer, F60 (4-Stroke) 1999 & Newer, 40 HP & 50 HP (not T50) 1984 & Newer, 48 HP 1995-00, 55 HP 1976-95, 60 HP 1976-91 (not T60); 13 tooth spline 3-1/4" Gearcase	RBX-117	17013300	C
T50 1996 & Newer, T60 2003 & Newer, 60 HP (not F60) 1992-05, 70-100 HP (not F75B, F90B) 1984 & Newer; 15 tooth spline 4-1/4" Gearcase	RBX-208	17015302	D
80-140 HP 1977-83; 15 tooth spline 4-1/4" Gearcase	RBX-102	17015300	D
F75B & F90B / 115 HP & 130 HP 1984 & Newer, F115 (4-Stroke) 2000 & Newer; 15 tooth spline 4-1/4" Gearcase	RBX-203	17015302	D
Same application as RBX-203 with Improved Shift Dampening and Vibration Reduction - Yamaha SDS Application (Rubber & Bronze Hub)	RBX-203B	17015301	D
150-175 HP 1978-83; 15 tooth spline 4-3/4"Gearcase	RBX-102	17015300	E
150-225 HP 1984 & Newer, 15 tooth spline	RBX-203	17015302	E
250 HP 1984 & Newer, 15 tooth spline; 300 HP (4 Stroke V6 Engine) 2004-2007 & 2010 & Newer; Sterndrives 1989-1993, 15 tooth spline	RBX-203B	17015301	E
300 HP (4-stroke V8 Engine), 350 HP (4-stroke V8 Engine); 17 tooth spline 5-1/4" Gearcase (Rubber & Bronze Hub)	RBX-127	17039300	E+
Nissan/Tohatsu
35 HP (35B only) Thru 1984, 40 HP 1984 & Newer, 50 HP (All except 50C) 1992 & Newer; 13 tooth spline 3-1/4" Gearcase	RBX-116	17013300	C
50 HP (50C only) 1987-91, 55 HP 1981-88, 60A 1986-99, 70A & 70B 1981-95; 13 tooth spline 3-1/4" Gearcase	RBX-112	17013300	C
60-140 HP (except 60A, 70A, & 70B) 1987 & Newer; 15 tooth spline 4-1/4" Gearcase	RBX-109	17015300	D
Honda
BF 35 & BF 45 1991-94, BF 40, 50, & 50A 1995 & Newer, BF 60 2010 & Newer; 13 Tooth Spline 3-1/4" Gearcase	RBX-113	17013300	C
BFP 60 2010 & Newer, BF 75 & BF 90 1999 & Newer, BF 115 1998-10, BF 130 1998-04; 15 Tooth Spline 4-1/4" Gearcase	RBX-107	17015300	D
BF 75-90 1995-98; 15 tooth spline 4-1/4" Gearcase	RBX-102	17015300	D
BF 115D 2011 & Newer, BF 135-250 2002 & Newer; 15 Tooth Spline 4-3/4" Gearcase	RBX-107	17015300	E
Application same as the RBX-107 (Rubber & Bronze Hub)	RBX-107B	17015301	E
OMC/Cobra Sterndrives
Model 400 Cobra 1978-91; 13 tooth spline 4-1/4" Gearcase	RBX-106	17024300	D
Model 800/Cobra/King Cobra 1978-90; 15 tooth spline 4-3/4" Gearcase	RBX-101	17025300	E
Model 800/Cobra/King Cobra 1991-94; 15 tooth spline 4-3/4" Gearcase	RBX-100	17025300	E
Cobra SX 1994 & Newer; 19 tooth spline 4-3/4" Gearcase	RBX-105	17075300	E
Force
40 & 50 HP 1995-98, 70 HP 1991-95, 75 HP 1996-98; 13 tooth spline 3-1/4" Gearcase	RBX-114	17013300	C
75-150 HP (Thru Hub Exhaust) 1995-99, 85-150 HP (Dual Exhaust) 1988-94; 15 Tooth Spline 4-3/4" Gearcase	RBX-102	17015300	D

Engine Make

Prop Size

Rubex Hub Kits

Clear

SKU: N/A Categories: Propellers, RUBEX 4 BLADE STAINLESS STEEL, RUBEX INTERCHANGEABLE HUB

Description

EXCELLENT CRUISING CHARACTERISTICS

GREAT STERN LIFT AND ACCELERATION
HIGH RAKE AND CUPPED BLADE DESIGN
POWERFUL THRUST AND VERY SMOOTH PERFORMANCE
INCREASED SPEED AND ECONOMY IN THE MID-RANGE

Additional information

Engine Make	Evinrude G2, Evinrude/Johnson, Mercury, Yamaha
Prop Size	14×21 LH 9554-140-21, 14×21 RH 9553-140-21, 14×23 LH 9554-140-23, 14×23 RH 9553-140-23, 14×25 LH 9554-140-25, 14×25 RH 9553-140-25, 14¼x17 LH 9554-143-17, 14¼x17 RH 9553-143-17, 14½x15 LH 9554-145-15, 14½x15 RH 9553-145-15, 14½x16 RH 9553-145-16, 14⅛x18 LH 9554-141-18, 14⅛x18 RH 9553-141-18, 14⅛x19 LH 9554-141-19, 14⅛x19 RH 9553-141-19
Rubex Hub Kits	RBX-100, RBX-102, RBX-151, RBX-203
